HWS-Series

Features

• RoHS compatible design(5th Generation Concept)
• Small-size package :minimizing 50%
• Unified stile size by 82mm height
• Available to enter for 2U rack-mount(19inch)
• Safety-terminal cover for live-electric parts as terminal block, it's enduring of safety from workers.



                   HWS-P Series


  Model name





• Features

  • Up to 3 times peak current.
  • High power in compact size.
  • Low acoustic noise due to automated control fan.
  • Follow HWS series concept.
  • Ideal for drive line load due its high reliability and easy-to-use.




             HWS/HD Series



    Model name

Features

• Suitable for rugged environment and heavy duty equipments
• -40°C～-10°C operating temperatures
• Coated circuit board
• Designed to meet MIL-STD-810F (shock and vibration)
• Safety terminal ”covering current flowing part secures safety for users.





                     HWS/ME-Series


  Model name





  Features

  • Medical Standard (EN60601/UL60601) approved
  • Leakage current less than 0.5mA
  • Safety terminal ”covering current flowing part secures safety for users.

※ JWS-Series (Single output 50W-600W)


Features

• CE marking (Low Voltage Directive)
• Wide input voltage range: Universal input 85～265VAC
• PFHC (EN61000-3-2)
• EMI (EN55011-B,EN55022-B,VCCI-B,FCC-B)
• EMS (EN61000-4-2,-3,-4,-5,-6)
• G2 : 5 year warranty






  ※ JWS-P Series (Peak current/ Single output 70-480W)



  Model name




  Features

  • CE marking(Low Voltage Directive)
  • Wide input voltage range : Universal input 85 ～ 265VAC
  • PFHC(EN61000-3-2)
  • EMI(EN55011-A,EN55022-A,VCCI-A,FCC-A)
  • EMS(EN61000-4-2,-3,-4,-5,-6)
  • G2 : 3 year warranty

               SWS-SERIES

Model name

Features

• All models conform to EN61000-3-2. (SWS100/150/300/600 with integral active PFC filter)
• Worldwide safety agency approvals: CE marking for LVD, UL/CSA/EN60950, EN50178
• EMI : Conform to EN55011-B, EN55022-B, FCC-B
• EMS: Conform to EN61000-4-2,3,4,5,6,8,11
• Screw terminal for input/output connections.



                SWS-L-SERIES


  Model name





  Features

  • Low Profile: slim design with the thin of 61mm
  • Wide operating temperature range （-20°C ～ + 74°C）
  • Temperature controlled fan
  • Reduced acoustic noise
